With the light and portable powered capstan winch with original Kawasaki engine TJ35E you can pull a variety of things from any terrain. The capstan winch is universal and goes with a constant pulling force of up to 1,000 kg it can be used for Boats, forestry, vehicles, search and rescue, large game and much more. With a pulley block (not included) you double the pulling power. A rope strength min. 8 mm, max. 10 mm, min 2500 kg breaking capacity is required (not included). The capstan winch is designed to pull a rope by rotating drum. The distance is limited only by the length of rope!
Specifications: Kawasaki 2 stroke engine, air-cooled, 1-cylinder, 35 cm ³ / 1,0 kw / 1.38 hp, gear rate 220:1, tank volume 0.7 l, torque 1,55 Nm at 5000 rpm, rope size min. 8mm max. 10mm polyester, dimensions approx 30cm (H) x 38cm (L) x 30cm (D), pulling up. 1.000kg, weight only 9 kg, train speed 9.5 m / min
Choose your way to conquer the terrain. The ZEON 10 is tough enough to tackle anything you will, with a look that is advanced, capable and strong. Muck-busting sealing keeps out everything but the good times. Add a hyper-durable cast-aluminum housing, satin-black finish, and 10,000 lbs. single-line pulling capacity and, well, you've got a workhorse unit you can trust for years to come.
The Centurion remote, designed & manufactured in Europe. The ultimate remote for the professional user.
CLOSELINK-Two-way CloseLink communication is at the heart of Centurion. Thanks to constant interaction between the handheld device and controller, the operator always has the situation under control, since intervention is possible at any time with maximum efficiency. The Controller constantly checks remote connection with the handheld device; if after a default time (300 ms for manned functions, 5 seconds for on/off functions), a correctly coded signal is not received, the controller goes in standby, resetting all the output to zero. Centurion also uses up to 15 transmission channels and proprietary algorithms for asynchronous communication to reduce the probability of interference with external sources to a minimum.
The 150m capacity in free space and without obstacles makes Centurion ideal for applications for operation at long distances, thanks to GFSK digital modulation that ensures maximum autonomy of 2,500 hours in stand-by and up to 200 hours of continuous transmission with 2 simple AAA batteries.
UNIQUENESS-Each Centurion system has a distinct source code which means it can also work with other Sistematica devices nearby and you can be assured that commands will only be exchanged among components on the same system: the 32 bit code enables distinct identification of over 4 billion handheld device-controller couplings. In the event of replacement it is possible to pair the new handheld device/controller with the due counterpart using a simple procedure, which can even be carried out by the end user.
IMPERMEABILITY-Centurion handheld devices & controllers are perfectly watertight, thanks to protection level IP67.
The volumetric ratios make the Centurion handheld device also ideal in nautical applications, enabling it to float; the impermeability of the controllers enable their installation also in locations exposed to the elements.
DURABILITY-The Centurion handheld devices are all manufactured in highly resistant moulded plastic with a rubber shell that makes its hold firmer and protects against knocks, even if dropped from a height of 4 metres.
The absence of mechanical elements enables functioning in unfavourable environments, with a temperature range from -20°C to +55°C.
ERGONOMICS-Buttons 10mm in diameter, with a wide inter-axis, with clear and effortless contact make the keypad suitable for all users. It is excellent in all those circumstances in which, for various reasons, user sensitivity is reduced or does not permit regulated force. The proportions of the handheld device are the result of appropriate assessment and enable easy, effortless hold. The contained weight and the reduced dimensions make it easy to use for everyone.
PROTECTION FROM POWER SUPPLY POLE IN VERSION- The use of specific components against power supply pole inversion guarantees the integrity of the device during installation and maintenance operations.
OUTPUT PROTECTION- All the output is protected from short circuits, surges and inverse voltage to enable parallel functioning with other actuators. The integration of recirculation diodes on the output make the device particularly indicated to command inductive loads, such as electro and solenoid valves, which no longer require the addition of external diodes
Superb high specification winch. Ideal for recovery and 4x4 applications. Outstanding features include high quality series wound double sealed motor with brass fittings, heavy duty waterproof contactors, double sealed drum on maintenance free bearings, quiet, efficient full steel planetary gearing.
Comes with stainless steel roller fairlead and fittings as standard. Complete with Heavy Duty integrated wireless remote.
110V 500KG SCAFFOLD HOIST
A NEW Warrior 2015 Patented designed model 110v portable hoist, its unique design and elegant shape which hooks to scaffolding and makes the job of getting building materials etc to upper storeys and roofs so much easier and safer. Suspending style with key interlock protection hook allows easy installation and safe working. New auto rope winding and direction exchange device allows steel rope to a line safely and without mess increasing the life of the rope by over 30 000 times. An ideal hoist for builders and roofers alike with 30m of usable cable.
High strength carbon construction with powder coated finish gives a strong and durable hoist. This hoist conforms to BS EN14492-2:2006 standard by a Internal dynamic brake design for both static, dynamic loading with standard with upper and lower limit switches and also thermol overload on the motor for added safety.
Maximum Lifting Capacity - 250kgs (36m) / 500kgs (18m) (Single Line / Double Line)
Cable Dia & Length - 4.2mm x 38m steel with swivel hook
Line Speed - 12m/min
Limit Switch For Safety - Upper & Lower
IP Rating - 65
Remote Length - 4m
Power Supply - 110v
Dimensions - (L)30 x (W)30 x (H)40cm (Not including wiring)
Weight - 36kgs
This 8,000 lb. capacity winch offers outstanding reliability and value. Its low-profile design allows for a variety of mounting options, making it perfect for most trucks, Jeeps and SUVs. .
Armortek synthetic winch rope is made using high strength HMPE light weight fiber.
Low strech, high strength & protected with Armortek's unique coating to improve abrasion resistance and protect from dirt, grit & oil.
